Radar level gauge is a commonly used liquid level measurement equipment, and the selection of its antenna is crucial to the measurement effect. This article will introduce how to correctly select a radar level gauge antenna to ensure measurement accuracy and stability.

1. Antenna type:

Rod antenna: suitable for general liquid level measurement, with good versatility and stability. Angular antenna: suitable for scenes with liquid buoys or floats, which can better penetrate the liquid surface for measurement. Antenna array: suitable for large storage tanks or complex scenes, capable of providing a wider measurement range and more accurate measurement results.

2. Working frequency:

26GHz frequency band: suitable for general liquid level measurement, with good anti-interference ability and high measurement accuracy. 6GHz frequency band: suitable for scenarios with high dielectric constant or high viscosity liquids, which can better penetrate the medium for measurement.

3. Antenna material:

Stainless steel antenna: corrosion-resistant, high-temperature resistant, suitable for harsh environments such as chemical industry. Polytetrafluoroethylene (PTFE antenna: has good chemical stability and corrosion resistance, and is suitable for food, pharmaceutical and other industries.

4. Antenna installation:

Installation location: The antenna should be installed at the highest point of the measured liquid to ensure accurate signal reception. Antenna angle: The antenna should be at a certain angle to the liquid surface, usually 45 degrees, to ensure that the signal penetrates the liquid surface.

Related questions:

What factors should be considered when selecting a radar level gauge antenna? Factors such as liquid properties, measurement accuracy requirements, environmental conditions, etc. should be considered to select the appropriate antenna type and operating frequency. How to determine the antenna installation location? The antenna should be installed at the highest point of the measurement liquid to ensure accurate signal reception. What scenarios are different types of antennas suitable for? The rod antenna is suitable for general liquid level measurement, the angular antenna is suitable for scenes with liquid buoys or floats, and the antenna array is suitable for large storage tanks or complex scenes. What effect does the antenna material have on the measurement? The material of the antenna affects its corrosion resistance and high temperature resistance. Antennas of different materials are suitable for different working environments.

Summary: The correct selection of radar level gauge antenna is crucial to the measurement effect. Factors such as antenna type, operating frequency, material and installation location should be considered, and reasonable selection should be made based on actual needs to ensure the accuracy and stability of measurement. sex.
